200Ah nominal capacity Max. Discharge current: 150A |
SolarV® Lithium iron phosphate (LiFePO4 or LFP) batteries are considered to be more environmentally friendly energy storage than traditional lead-acid batteries, and they comply with the European RoHS regulations. Lithium storage batteries boast excellent safety, reliability and high efficiency. The high number of cycles ensures a long lifespan and up to 80% usable capacity without deep discharge. The integrated BMS in our LiFePO4 battery ensures a high level of protection functions to safeguard against overvoltage and overcharging.The SolarV® LiFePO4 batteries offer a proven advantage with their unparalleled energy storage to weight ratio – a weight savings of over 60% compared to AGM/Gel batteries. With the newly integrated Bluetooth communication feature, it enables operational monitoring through our Smart App for iOS and Android devices. Recommended applications include campervans, boats, PV systems, recreational applications and uninterruptible power supplies (UPS).
Manufacturer model | 12.8V 200Ah LiFePO4 BATTERY |
---|---|
EAN Code | 4260558573920 |
Article Number | 4912200 |
Rated Voltage | 12.8V |
Rated Capacity at 25°C | 200Ah |
Rated Energy at 25°C | 2560Wh |
Resistance | ≤ 20mΩ |
Efficiency | ≥ 0.98 |
Cycle Life (80% Depth of Discharge, 1C) | > 2000 Cycles |
Continuous Discharge Current | 150A |
Recommended Discharge Voltage | 10V |
Short Circuit Protection | 300-800us |
Charge Voltage | 14.2V to 14.6V |
Float Voltage | 13.5V to 13.8V |
Maximum Charge Current | 150A |
Recommended Charge Current | ≤ 75A |
Operating Temperature | Discharge: -20°C to 60°C Charge: 0°C to 55°C |
Storage Temperature | -20°C bis 60°C |
BMS Protection Temperature | 65°C |
Cell Type | LiFePO4 |
Communication | Bluetooth (max. distance 30m) |
Power Connection | M8 |
Protection Class | IP65 |
Dimension (LxWxH) | 483x170x240 mm |
Weight | 19.5kg |
PAS SOLAR is a Distributer of solar equipment based in UAE. Composed of a team of professionals with the goal to provide customers with the latest Tier 1 Solar system in the region.
