| Hybrid 15 KW Three Phase 48 V
5 Years Warranty |
· Max. charging/discharging current of 290A
· 100% unbalanced output꞉ each phase up to 50% rated power
· 200% overload capability for 10 seconds
· Support UPS function and black start
· Integrated with generator input and
smart load contro
$ 1,755
| Datasheet | WIT 8K-HU | WIT 10K-HU | WIT 12K-HU | WIT 15K-HU |
| Input data (PV) | ||||||||
| Max. recommended PV power (for module STC) | 12800W | 16000W | 19200W | 24000W | ||||
|
1000V | |||||||
| Start voltage | 160V | |||||||
|
600V | |||||||
| MPPT voltage range | 160V-850V | |||||||
|
20A+20A | 40A+20A | ||||||
| Max. short-circuit current per MPP tracker | 25A+25A | 50A+25A | ||||||
|
1+1 | 2+1 | ||||||
| No. of MPP trackers | 2 |
|
12000W | ||||
| AC nominal power | 8000W | 10000W | 15000W | ||
|
8800VA | 11000VA | 13200VA | 16500VA | |
| Nominal AC voltage/range | 220V/230V, 380V/400V, -15%~+10% | ||||
|
50/60Hz, 45~55Hz/55-65 Hz | ||||
| Max. output current | 13.3A@220V, 12.8A@230V | 16.7A@220V, 15.9A@230V | 20A@220V, 19.1A@230V | 25A@220V, 23.9A@230V | |
|
-1…+1 | ||||
| THDi | <3% | ||||
|
3P3W+PE/3P4W+PE | ||||
| Input data (AC) | 24000W | |||
| AC nominal power | 16000W | 20000W | 30000W | |
| Max. AC apparent power | 17600VA | 22000VA | 26400VA | 33000VA |
| Nominal AC voltage/range | 220V/230V, 380V/400V, -15%~+10% | |||
| Nominal AC grid frequency/range | 50/60Hz, 45~55Hz/55-65 Hz | |||
| Max. input current | 26.6A@220V, 25.5A@230V | 33.3A@220V, 31.9A@230V | 40A@220V, 38.3@230V | 50.1A@220V, 47.8A@230V |
| Battery data (DC) | |||||
| Battery type | Lead-acid or Lithium-ion | ||||
| Battery voltage range | 40-60V | ||||
| Max charging and discharging current | 200A | 220A | 250A | 290A | |
| Recommended battery voltage | 51.2V | ||||
| BMS communication | RS485/CAN |
|
12000W | ||||
| Rated AC output power | 8000W | 10000W | 15000W | ||
|
2 time of rated power, 10s | ||||
| Rated AC output voltage | 220V/230V, 380V/400V | ||||
|
50/60Hz | ||||
| Max. output current | 24.2A@220V 23.2A@230V |
30.3A@220V 29A@230V |
36.4A@220V 34.8A@230V |
45.5A@220V 43.4A@230V |
|
|
3% (Linear load) | ||||
| Load unbalance | 100% three-phase unbalanced | ||||
|
10ms | ||||
| Efficiency | |
| Max. efficiency | 97.60% |
| European efficiency | 97.00% |
| MPPT efficiency | 99.90% |
|
||
| PV reverse polarity protection | Yes | |
|
Yes | |
| DC/AC surge protection | Type II/Type III | |
|
Yes | |
| Residual-current monitoring unit | Yes | |
|
Yes | |
| Ground fault monitoring | Yes | |
|
Yes | |
| Strings monitoring | Yes | |
|
Yes | |
| PID protection | Opt | |
|
Opt |
| General | ||
| Dimensions (W / H / D) | 422/658/254mm | |
|
38kg | |
| Operating temperature range | –30°C … +60°C (> 45°C, derating) | |
|
≤50dB(A) | |
| Relative humidity | 0~100% | |
|
3000m | |
| Topology | Transformerless | |
|
Smart air cooling | |
| IP degree | IP66 | |
|
OLED/LED+APP | |
| Interfaces: RS485/USB | Yes | |
|
Yes | |
| Warranty (5/10 years) | Yes/Opt |
If you’re planning a small-scale solar project and looking for an inverter that’s both powerful and easy to manage, the Growatt WIT 15K-HU is definitely worth considering. With a 15 kW capacity, it’s perfect for residential setups or light commercial use. One of the standout features is its smart monitoring system, which lets you keep an eye on performance in real time — no surprises, no stress. It also offers solid efficiency and a compact design that doesn’t take up much space. Whether you’re comparing options or ready to buy, this model gives you excellent value for its price. It’s a well-balanced choice for anyone serious about long-term energy savings without overcomplicating things.
PAS SOLAR is a Distributer of solar equipment based in UAE. Composed of a team of professionals with the goal to provide customers with the latest Tier 1 Solar system in the region.
