The Trina Solar Vertex N 630W has been engineered with exactly that goal in mind. Combining advanced N-Type i-TOPCon cell technology, a durable dual-glass bifacial design, and the proven 210 mm cell platform, this module delivers exceptional efficiency, long-term reliability, and impressive energy yield across a wide range of environmental conditions.
| Parameter | Specification |
|---|---|
| Product Series | Trina Solar Vertex N |
| Model | TSM-NEG19RC.20 |
| Nominal Power Output | 630W |
| Power Range | 610W – 635W |
| Module Efficiency | Up to 23.5% |
| Cell Technology | N-Type i-TOPCon Monocrystalline |
| Module Type | Bifacial Dual Glass |
| Number of Cells | 132 Half-Cut Cells |
| Power Tolerance | 0 ~ +5W |
| Maximum System Voltage | 1500V DC |
| Maximum Series Fuse Rating | 35A |
| Operating Temperature | -40°C to +70°C |
| Temperature Coefficient (Pmax) | -0.29%/°C |
| Temperature Coefficient (Voc) | -0.24%/°C |
| Temperature Coefficient (Isc) | +0.04%/°C |
| NOCT | 43°C ±2°C |
| Product Warranty | 12 Years |
| Performance Warranty | 30 Years |
| First-Year Degradation | 1% |
| Annual Degradation | 0.4% |
| Power Output After 30 Years | 87.4% |
| Certifications | IEC 61215, IEC 61730, ISO 9001, ISO 14001, ISO 14064, ISO 45001, ISO 14067 |
| Parameter | Specification |
|---|---|
| Cell Type | N-Type i-TOPCon Monocrystalline |
| Number of Cells | 132 Cells |
| Module Dimensions | 2382 × 1134 × 30 mm |
| Weight | 33.0 kg |
| Front Glass | 2.0 mm AR Coated Heat-Strengthened Glass |
| Back Glass | 2.0 mm Heat-Strengthened Glass (White Coating) |
| Frame | 30 mm Anodized Aluminium Alloy |
| Junction Box | IP68 Rated |
| Cable | 4.0 mm² Photovoltaic Cable |
| Connector | MC4 EVO2 / TS4 Compatible |
| Model | 610W | 615W | 620W | 625W | 630W |
|---|---|---|---|---|---|
| Maximum Power (Pmax) | 610W | 615W | 620W | 625W | 630W |
| Voltage at Pmax (Vmp) | 39.79V | 39.97V | 40.24V | 40.46V | 40.68V |
| Current at Pmax (Imp) | 15.33A | 15.39A | 15.41A | 15.45A | 15.49A |
| Open Circuit Voltage (Voc) | 48.09V | 48.29V | 48.50V | 48.70V | 48.90V |
| Short Circuit Current (Isc) | 16.14A | 16.20A | 16.26A | 16.32A | 16.38A |
| Module Efficiency | 22.6% | 22.8% | 23.0% | 23.1% | 23.3% |
| Model | 610W | 615W | 620W | 625W | 630W |
|---|---|---|---|---|---|
| Pmax | 465W | 469W | 473W | 477W | 481W |
| Vmp | 37.60V | 37.80V | 37.90V | 38.10V | 38.30V |
| Imp | 12.38A | 12.43A | 12.47A | 12.52A | 12.57A |
| Voc | 45.70V | 45.90V | 46.10V | 46.30V | 46.50V |
| Isc | 13.00A | 13.05A | 13.10A | 13.15A | 13.20A |
| Rear Side Gain | Equivalent Power (630W Model) |
|---|---|
| 0% | 630W |
| 5% | 662W |
| 10% | 693W |
The Trina Solar Vertex N series is available in power classes ranging from 610W to 635W. This page focuses on the popular 630W configuration, offering high efficiency and reliable performance for utility-scale and commercial solar projects.
Yes. It features a bifacial dual-glass design, allowing the rear side of the module to capture reflected sunlight and increase total energy production depending on installation conditions.
The module is built using advanced N-Type i-TOPCon monocrystalline half-cut cells, providing higher efficiency, lower degradation, and improved performance under low-light conditions.
This module is ideal for utility-scale solar farms, commercial and industrial rooftops, tracker systems, agrivoltaic projects, floating PV installations, and large off-grid solar systems.
Yes. Thanks to its low temperature coefficient and advanced N-Type cell technology, the module maintains excellent performance even in high-temperature environments.
What is the maximum power output of the Trina Solar Vertex N 630W?
Is the Trina Solar Vertex N 630W a bifacial solar panel?
What type of solar cells does this module use?
What applications is the Trina Solar Vertex N 630W best suited for?
Does the module perform well in hot climates?
