$ 220
The power station uses LiFePO4 battery technology, providing a 1004Wh energy capacity and a rated battery capacity of 314Ah. The battery is specified for more than 4000 cycles, making it suitable for applications that involve regular charging and discharging.
| Battery Specification | Value |
|---|---|
| Battery Energy | 1004Wh |
| Battery Capacity | 314Ah |
| Battery Chemistry | LiFePO4 |
| Battery Lifecycle | 4000+ Cycles |
The LiFePO4 chemistry provides a rechargeable energy storage platform for portable backup and off-grid applications.
The INFINITY 1000 can be recharged through an AC power source or a compatible photovoltaic input. Its solar charging interface accepts between 12V and 60V DC and supports up to 200W of PV input power.
| Charging Specification | Value |
|---|---|
| AC Input Voltage | 220V |
| AC Input Frequency | 45–65Hz |
| AC Input Power | 300W |
| Maximum PV Input Power | 200W |
| PV Input Voltage Range | 12–60V |
| Full Recharge Time | Within 3.5 hours |
The PV input allows the unit to function as a portable solar power station, providing an additional charging option for outdoor and off-grid use when a suitable solar source is available.
For powering connected equipment, the system provides one 220V AC output together with USB-A and USB-C ports. The AC section delivers 300W of rated power and can reach 600W under peak conditions.
| Output Specification | Value |
|---|---|
| AC Output | 1 × 220V, 50/60Hz |
| Rated AC Output | 300W |
| Peak AC Output | 600W |
| USB-A | 2 × 5/9/12V, 20W Max. |
| USB-C | 1 × 5/9/12V, 20W Max. |
This configuration makes the unit suitable for supplying power to compatible electronic equipment and charging USB-powered devices from a single battery-based source.
The integrated UPS function allows the power station to provide backup power when the incoming AC supply is interrupted. The specified transfer time is less than 12ms.
| Function | Specification |
|---|---|
| UPS Mode | Available |
| UPS Transfer Time | <12ms |
| Bypass Mode | Available |
| Trickle Charging | Available |
| Cooling | Fan Forced-Cooling |
The short transfer time can be useful for compatible equipment that needs a rapid transition from utility power to battery power.
The power system incorporates several protective functions designed to monitor electrical and thermal operating conditions. Battery status is displayed through four LED indicators.
| Protection / Monitoring | Availability |
|---|---|
| Overload Protection (OLP) | Yes |
| Overvoltage Protection (OVP) | Yes |
| Overcurrent Protection (OCP) | Yes |
| Overtemperature Protection (OTP) | Yes |
| Low Voltage Protection (LVP) | Yes |
| Battery SOC Indicator | 4 LEDs |
These functions help monitor the operating condition of the unit and provide basic protection against abnormal electrical or temperature conditions.
| Parameter | Specification |
|---|---|
| Product Type | Portable Power Station |
| Battery Energy | 1004Wh |
| Battery Capacity | 314Ah |
| Battery Chemistry | LiFePO4 |
| Battery Lifecycle | 4000+ Cycles |
| Rated AC Output | 300W |
| Peak AC Output | 600W |
| AC Voltage | 220V |
| Maximum PV Input | 200W |
| PV Voltage Range | 12–60V |
| USB-A Ports | 2 × 20W Max. |
| USB-C Port | 1 × 20W Max. |
| UPS Transfer Time | <12ms |
| Full Recharge Time | Within 3.5 hours |
| Cooling System | Fan Forced-Cooling |
| Battery SOC Indicator | 4 LEDs |
Before selecting this power station for a particular application, consider the following specifications:
| Selection Factor | INFINITY 1000 |
|---|---|
| Stored Energy | 1004Wh |
| Continuous AC Power | 300W |
| Maximum AC Peak Power | 600W |
| Solar Charging Capacity | 200W |
| Solar Input Voltage | 12–60V |
| Battery Technology | LiFePO4 |
| Rated Battery Cycles | 4000+ |
| UPS Transfer Time | <12ms |
| USB Charging | USB-A + USB-C |
| Full Recharge | Within 3.5 hours |
It has a battery energy capacity of 1004Wh and a rated battery capacity of 314Ah. It uses LiFePO4 battery chemistry and is specified for more than 4000 charge cycles.
It is designed for compatible electrical loads within its 300W continuous AC rating, with up to 600W available as peak power. The required starting and operating power of the connected device should always be checked before use.
The unit supports AC charging and photovoltaic charging. Its solar input accepts 12V to 60V and supports up to 200W of PV input power.
Yes. Its portable battery-based design, AC output, USB charging ports and solar input make it suitable for compatible outdoor, travel and off-grid applications.
The UPS function allows the unit to transition to battery power when the AC supply is interrupted. The specified transfer time is less than 12ms.
The product specifications state that the battery can be fully recharged within approximately 3.5 hours.
Yes. The power station uses a LiFePO4 battery with 1004Wh of energy capacity, 314Ah capacity and a rated lifecycle of more than 4000 cycles.
Yes. The INFINITY 1000 has a dedicated PV input with a 12–60V operating range and a maximum solar input power of 200W. The solar source must meet the specified input requirements.
The unit provides two USB-A outputs and one USB-C output. The listed USB outputs support 5V, 9V and 12V operation with a maximum output of 20W.
The INFINITY 1000 includes overload, overvoltage, overcurrent, overtemperature and low-voltage protection. Battery state of charge is indicated through four LEDs.
How much energy can the Growatt portable powerstation store?
What can a 300W portable power station run?
How can the Growatt INFINITY be recharged?
Is the INFINITY 1000 suitable for outdoor use?
What does the UPS function do on This power station?
How long does it take to recharge the battery completely?
Does the INFINITY 1000 use a LiFePO4 battery?
Can solar panels be used to charge this power station?
What charging ports are available for electronic devices?
What safety protections are built into the power station?
