| On Grid 15 KW Three Phase
5 Years Warranty |
· Max.efficiency 98.75%
· Dual MPP trackers
· Touch key and OLED display
· Type II SPD on AC and DC side
· AFCI function optional
$ 890
| Datasheet | MID 15KTL3-X | MID 17KTL3-X | MID 20KTL3-X | MID 22KTL3-X | MID 25KTL3-X |
| Input data (DC) | |||||
| Max. recommended PV power (for module STC) | 22500W | 25500W | 30000W | 33000W | 37500W |
| Max. DC voltage | 1100V | ||||
| Start Voltage | 250V | ||||
| Normal Voltage | 580V | ||||
| MPPT voltage range | 200V-1000V | ||||
| No. of MPP trackers/strings per MPP tracker | 2/2 | 2/2 | 2/2 | 2/2 | 2/3 |
| Max.input current per MPP tracker | 27A | 27A | 27A | 27A | 27A/40.5A |
| Max. short-circuit current per MPP tracker | 33.8A | 33.8A | 33.8A | 33.8A | 33.8A/50.7A |
| Output data (AC) | |||||
| Rated AC output power | 15000W | 17000W | 20000W | 22000W | 25000W |
| Max. AC apparent power | 16600VA | 18800VA | 22000VA | 24400VA | 27700VA |
| Nominal AC voltage(range*) | 230V/400V; 340-440V | ||||
| AC grid frequency;(range*) | 50/60 Hz; 45~55Hz/55-65 Hz | ||||
| Max. output current | 24.2A | 27.4A | 31.9A | 35.5A | 40.2A |
| Adjustable power factor | 0.8 leading – 0.8 lagging | ||||
| THDi | <3% | ||||
| AC grid connection type | 3W+N+PE | ||||
| Efficiency | |||||
| Max.efficiency | 98.75% | ||||
| European efficiency | 98.6% | ||||
| MPPT efficiency | 99.9% | ||||
| Protection devices | |||||
| DC reverse polarity protection | Yes | ||||
| DC Switch | Yes | ||||
| AC/DC surge protection | Type II / Type II | ||||
| Insulation resistance monitoring | Yes | ||||
| AC short-circuit protection | Yes | ||||
| Ground fault monitoring | Yes | ||||
| Grid monitoring | Yes | ||||
| Anti-islanding protection | Yes | ||||
| Residual-current monitoring unit | Yes | ||||
| String monitoring | Yes | ||||
| AFCI protection | Optional | ||||
| General data | |||||
| Dimensions (W / H / D) | 525/395/222mm | ||||
| Weight | 23kg | ||||
| Operating temperature range | –25 °C … +60 °C | ||||
| Self-Consumption (night) | < 1W | ||||
| Topology | Transformerless | ||||
| Cooling | Smart air cooling | ||||
| Protection degree | IP65 | ||||
| Relative Humidity | 0~100% | ||||
| Altitude | 4000m | ||||
| DC connection | H4/MC4(Optional) | ||||
| AC connection | Cable gland+OT terminal | ||||
| Display | OLED+LED/WIFI+APP | ||||
| Interfaces: RS485 / USB / WiFi/ GPRS / RF/ LAN | Yes/Yes /Optional/Optional/Optional/Optional | ||||
| Warranty: 5 years / 10 years | Yes/Optional | ||||
| CE, VDE0126, Greece, EN50549-1, C10/C11, UTE C 15-712, IEC62116, IEC61727, IEC 60068, IEC 61683, CEI0-21, N4105, G98/G99, G100, KSC8565 | |||||
The Growatt Inverter MID 15KTL3-X is an ideal solution for small commercial and residential solar systems. Offering 15 kW of efficient power output, this inverter helps users reduce electricity bills and increase their reliance on clean, renewable energy. If you’re looking to buy a dependable inverter at a competitive price, the MID 15KTL3-X provides excellent value.
This model features high conversion efficiency, meaning more sunlight is turned into usable electricity for your home or business. Its durable design ensures consistent performance even in tough weather or unstable voltage conditions, minimizing downtime and maintenance costs. This reliability makes it a smart long-term investment.
The MID 15KTL3-X comes equipped with smart monitoring capabilities, allowing you to keep track of your solar system’s performance remotely. This makes management easy and helps quickly identify any issues before they affect energy production. Installation is flexible and straightforward, suitable for a variety of setups.
In terms of price, the Growatt MID 15KTL3-X offers a good balance between affordability and advanced technology. The initial cost is offset by energy savings over time, making it a cost-effective choice. Growatt’s solid warranty and global support provide added peace of mind.
In summary, if you want to buy a reliable, efficient, and reasonably priced inverter for your small solar project, the Growatt MID 15KTL3-X is a smart choice. It combines strong performance, smart features, and durability to help you get the most from your solar investment.
