| Hyrbid 12 KW Single Phase 48 V
5 Years Warranty |
· Dual MPP trackers
· Maximum PV input voltage up to 550VDC
· Two AC input terminals with integrated transfer switch
· Featuring grid-tied function for peak shaving
· Support parallel operation for capacity expansion up to 108kW.
· Dual outputs for smart load management
$ 887
| Datasheet | SPE 8000 ES | SPE 10000 ES | SPE 12000 ES |
| Input data (DC) | |||
| Max. recommended PV power
(for module STC) |
10000W | 12500W | 15000W |
| Max. DC voltage | 550V | ||
| Start voltage | 120V | ||
| MPP voltage range | 60V-480V | ||
| No. of MPP trackers | 2 | ||
| No. of PV strings per MPP tracker | 1 | ||
| Max. input current per MPP tracker | 27A | ||
| Output data (AC) | |||
| AC nominal power | 8000W | 10000W | 12000W |
| Max. AC apparent power | 8000VA | 10000VA | 12000VA |
| Nominal AC voltage | 230V | ||
| AC grid frequency | 50/60Hz | ||
| Output current | 34.8A | 43.5A | 52.2A |
| Adjustable power factor | 0.8leading…0.8lagging | ||
| THDi | < 5% | ||
| Max. conversion efficiency (PV/AC) | 96.5% | ||
| European efficiency @ vnominal (PV/AC) | 95.5% | ||
| Battery data (DC) | |||
| Nominal DC voltage | 48V | ||
| Max charging and discharging current | 190A/200A | 220A/240A | 250A/280A |
| Type of battery | Lithium/Lead-acid | ||
| Backup power (AC) | |||
| AC nominal output power | 8000W | 10000W | 12000W |
| Nominal AC output voltage | 230V | ||
| Nominal AC output frequency | 50/60Hz | ||
| Switch time | <20ms@Single
<30ms@Parallel |
||
| Efficiency | |||
| Peak. efficiency | 96.5% | ||
| European efficiency | 95.5% | ||
| General data | |||
| Dimensions (W / H / D) | 550/465/150mm | ||
| Weight | 21.5kg | ||
| Operating temperature range | –10°C … +50°C | ||
| Noise emission (typical) | ＜75dB | ||
| Self-consumption | < 75W | ||
| Topology | Tranformerless | ||
| Cooling | DC fan | ||
| Protection degree | IP20 | ||
| Relative humidity | 5%~95% non-condensing | ||
| Altitude | ＜2000m | ||
| Communication | WiFi/4G | ||
| CE, NRS097 | |||
Solar energy systems are the cornerstone in the rapidly changing age of renewable energy to ensure a green lifestyle. Of all the components making up a solar energy system, the inverter plays the most crucial role. It converts the alternating current (AC) generated by solar panels into direct current (DC) usable by households and businesses. We spotlight today the Growatt Inverter SPE12000ES, a very efficient and long-lasting model for anyone looking for efficiency, longevity, and advanced features.
The Growatt SPE12000ES is a powerful Off grid Growatt Inverter designed for solar energy systems that operate independently from the grid.
The Growatt Inverter SPE12000ES is a small commercial and residential gridtied solar inverter that is one of the excellent series of inverter solutions by Growatt that combine cuttingedge technology with simplicity. The 12 kW rated SPE12000ES model is ideally designed for mediumsized solar systems to offer a perfect combination of performance and costeffectiveness.
This inverter is designed for maximum energy harvesting, system protection, and ease of maintenance and thus is a darling to both solar professionals and hobbyists.
High Efficiency: Growatt Inverter SPE12000ES has a peak efficiency of more than 98%, and thus you are guaranteed minimal energy loss and thus maximum energy for your business or residence.
Strong Construction: Rugged casing and efficient cooling systems to sustain the various environmental conditions.
Smart Monitoring: The system has been put on Growatt’s smart monitoring platform, and the system can be remotely monitored via desktop or mobile.
Compatibility: It is capable of supporting various kinds of batteries that provide flexibility in the future to expand or store.
Safety Features: It includes antiislanding protection, overvoltage, and overcurrent protections for security.
12k growatt inverter is the name given to the 12-kilowatt power rating of the inverter, making it an ideal fit for mediumsized solar installations. If you’re installing a new system or replacing an old one, this inverter provides the capacity to accept high energy input with extraordinary performance.
The growatt 12kw inversor is equally easy to install and reliable, making it a favorite with installers and home owners. Its capacity enables system design in flexible configurations, where various panel orientations are used to optimize energy yield.
|
Feature |
Specification |
|
Model |
Growatt Inverter SPE12000ES |
|
Power Capacity |
12 kW |
|
Max. Efficiency |
98.1% |
|
MPPT Channels |
2 |
|
Input Voltage Range |
200V – 1000V |
|
Weight |
Approximately 25 kg |
|
Dimensions |
560mm x 420mm x 200mm |
|
Cooling System |
Forced air cooling |
|
Communication |
WiFi, USB, RS485 |
Note: Always refer to the Growatt Inverter SPE12000ES manual for full technical data and installation requirements.
Price is always a consideration when selecting a solar inverter. The price of Growatt Inverter SPE12000ES is reasonable in the market and provides excellent value for its reliability and performance. Price will depend on where you are, your dealer, and whether you opt to add more features or warranties.
Its price normally ranges from $1,200 to $1,500 USD. Make sure that you compare prices with authorized dealers and that the inverter comes with manufacturer guarantees and technical assistance.
Buying a Growatt inverter like the SPE12000ES not only provides a stable energy conversion option but also guarantees long-term cost savings through high efficiency and longevity.
If you’re looking for the Growatt inverter price list, be sure to check with authorized distributors or visit the official website for the most up-to-date pricing information.
1. Site Survey: Ensure your installation site is proper — outside shade, with ventilation.
2. System Design: Design number of solar panels to be equal to inverter capacity.
3. Installation: Check Growatt Inverter SPE12000ES user manual for wiring, grounding, and safety instructions.
4. Configuration: Configure parameters using monitoring system or interface of inverter.
5. Monitoring & Maintenance: Periodically check system performance using the app or web portal, and perform maintenance according to recommendations.
Growatt has built a good reputation in the solar industry by its focus on quality, innovation, and customer services. Its products, such as SPE12000ES, have global recognition for:
Reliability: Established track record in diverse conditions.
Innovation: Installation of new technology for maximum performance.
Affordability: Highly affordable with excellent ROI.
Support: Exceptional customer support and comprehensive manuals.
Why Growatt Inverter SPE12000ES? Having an appropriate inverter can either make or ruin your solar power system’s performance. The Growatt Inverter SPE12000ES is a cost-effective, efficient, and versatile solution for those who wish to harness the energy of the sun effectively. Its high efficiency, robust design, and comprehensive monitoring capabilities make it a top choice for both residential and small commercial applications. Growatt, as a good brand in the solar industry, continues to innovate and support customers worldwide. Investing in a Growatt inverter like the SPE12000ES ensures you’re partnering with a trusted name committed to clean energy and customer satisfaction. Begin your solar adventure today with the Growatt Inverter SPE12000ES and enjoy decades of clean, dependable power!
Known for its efficiency and reliability, it’s a popular choice for solar power Dubai projects, ensuring maximum energy conversion and smart energy management.
Yes, it’s just right for mediumsized residential solar systems.
You can get the manual from Growatt’s official website or your installer.
Yes, it allows different configurations and pairs of batteries for possible future expansion.
It is also recommended to check from time to time, clean, and have the system alert you.
Indeed, Growatt is renowned throughout the world for making long-lasting and efficient inverters.
