It’s especially popular among customers looking for solar products in Dubai, thanks to its durability and compatibility with various battery types.
| Off Grid 3 KW Single Phase 24 V
5 Years Warranty |
· Integrated MPPT charge controller
· Configurable grid or solar input priority
· Optional WIFI/ GPRS remote monitoring
· Parallel for scalability
$ 192
| Datasheet | SPF 2000TL HVM-24 | SPF 3000TL HVM-24 | SPF 2000TL HVM-48 | SPF 3000TL HVM-48 | SPF 5000TL HVM/HVM-P |
| Battery Voltage | 24VDC | 48VDC | |||
| Battery Type | Lithium/Lead-acid | ||||
| INVERTER OUTPUT | |||||
| Rated Power | 2000VA/ 2000W | 3000VA/ 3000W | 2000VA/ 2000W | 3000VA/ 3000W | 5000VA/ 5000W |
| Parallel Capability | No | No/ Yes，6 units maximum | |||
| AC Voltage Regulation (Battery Mode) | 230VAC ± 5%
@ 50/60Hz |
||||
| Surge Power | 4000VA | 6000VA | 4000VA | 6000VA | 10000VA |
| Efficiency (Peak) | 93% | ||||
| Waveform | Pure sine wave | ||||
| Transfer Time |
10ms typical, 20ms Max |
||||
| SOLAR CHARGER | |||||
| Maximum PV Array Power | 1500W | 1800W | 4500W | ||
| MPPT Range @ Operating Voltage | 30VDC ~ 80VDC | 60VDC ~ 115VDC | |||
| Maximum PV Array Open Circuit Voltage |
102VDC |
145VDC |
|||
| Number of Independent MPP Trackers/ Strings Per MPP Tracker | 1/1 | ||||
| Maximum Solar Charge Current | 50A | 30A | 80A | ||
| Maximum Efficiency | 98% | ||||
| AC CHARGER | |||||
| Charge Current | 30A | 15A | 60A | ||
| AC Input Voltage | 230 VAC | ||||
| Selectable Voltage Range | 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances) | ||||
| Frequency Range | 50Hz/60Hz (Auto sensing) | ||||
| PHYSICAL | |||||
| Protection Degree | IP20 | ||||
| Dimension (W/H/D) | 315/400/130mm | 350/455/130mm | |||
| Net Weight (kgs) | 8 | 8.5 | 8 | 8.5 | 11.5 |
| OPERATING ENVIRONMENT | |||||
| Humidity |
5% to 95% Relative Humidity(Non-condensing) |
||||
| Altitude | <2000m | ||||
| Operating Temperature | 0°C – 55°C | ||||
| Storage Temperature | -15°C – 60°C | ||||
With increasingly greener options for energy now more important to our planet than ever, the Growatt Inverter SPF 3000TL HVM-24 is an incredibly powerful and very versatile option for residential and business solar installations. Whether you need sun power harvesting for off-grid or searching for a hybrid inverter to go hand-in-hand with your energy storage solution, Growatt SPF 3000TL HVM-24 is an excellent set of features covering various needs. Let’s get inside this revolutionary inverter and find out more about its specifications, benefits, and why it must be the focal point on your clean energy side.
Growatt Inverter SPF 3000TL HVM-24 is a hybrid inverter for full utilization of solar power. It can feed into the grid and operate in off-grid mode as well, and hence it is a universal machine to cater to fluctuating demands for energy. With the capability of the new generation technology, the inverter can supply a power of 3kW at 24V, thus being the best for use in small to medium-sized solar systems.
This inverter is highly sought after by residential customers and small business organizations alike who would want to get the maximum out of their solar investment and also enjoy the freedom of energy independence. As this has the ability to function in off-grid, grid-tie, or hybrid mode, this is a never-been-seen-before piece of equipment and hence is coveted by those looking for a durable, long-term, and effective solar inverter.
In as much as one is to get to know the value of the Growatt SPF 3000TL HVM-24, one must take the time to get to know its major features. The following is a detailed analysis:
|
Feature |
Description |
|
Hybrid Functionality |
There is the availability of off-grid and grid-connecting ability, and it is simple to change from either to the other. |
|
Power Rating |
Consistently provides an output power of 3kW, well-suited for small solar panels. |
|
Voltage Compatibility |
Allows compatibility with 24V systems, thus compatible with heterogeneous varieties of batteries. |
|
High Efficiency |
97% efficiency top for optimal conversion of energy with least wastage. |
|
Built-in MPPT Charge Controller |
Optimal harvesting of solar energy for optimal system operation. |
|
Multiple Operating Modes |
Three modes of grid mode, off-grid mode, and hybrid mode support to provide flexibility in installation facilitation. |
|
Display & User Interface |
LCD user interface to read system parameters and settings directly in real-time. |
|
Protection Features |
Over-voltage, under-voltage, overload, and short-circuit protection for security and extend lifespan. |
|
Compatibility |
High compatibility with a variety of batteries, including lithium-ion and lead-acid batteries. |
|
Remote Monitoring |
Remote control of the system using the Growatt Shine App or other compatible platforms. |
One of the most impressive aspects of the growatt spf 3000tl hvm-24 datasheet is its simplicity. If you are looking for a growatt spf 3000tl hvm-24 review or simply want to read the growatt spf 3000tl hvm-24 manual, you will find that you can easily access comprehensive materials to aid your installation and use.
This inverter is broadly desired by individuals looking for an off-grid inverter system as its structure can be adjusted for use with solar stand-alone systems with or without the grid. The specifications are all included in the growatt spf 3000tl hvm-24 datasheet, and confirmation can be established with users’ installed or intended system components to validate compatibility.
It’s especially popular among customers looking for solar products in Dubai, thanks to its durability and compatibility with various battery types.
It is ideal for:
The 3kw growatt spf 3000tl hvm 24 24v inverter is a strong and light system for the customer who needs to harness all the available solar power and has the capability of operation on dual modes.
Why are people drawn to the Growatt Inverter SPF 3000TL HVM-24? Here are some sought-after features:
With up to 97%, this inverter gets maximum solar energy attained and converts it into energy with fewer losses to wastage.
Grid connection, off-grid, or hybrid mode, whichever working mode one wants, this inverter is all about it, hence an easy-to-use product for any use.
Sheltered to a great degree, SPF 3000TL HVM-24 provides safe use, its lifespan even in harsh environments.
Benefiting from its user-friendly interface as well as remote monitoring facility, ease of system monitoring is provided, operators able to monitor conveniently online in real-time via apps or websites.
Compatibility with different battery chemistries such as lithium-ion and lead-acid provides design freedom in the event of your energy storage solutions.
Its compact space-saving design enables it to have an ideal fit in confined spaces both indoors and outdoors.
Growatt has been a major supplier of clean energy solutions for decades now and is well reputed to make low-cost, efficient, and innovative inverters. Growatt inverters like the growatt spf 3000tl hvm-24 datasheet and more are highly in demand globally. Growatt is a very trusted brand among professionals and hobbyists due to its dedication towards customer satisfaction, quality, and continuous technological enhancement.
If you’re comparing options, the Growatt inverter price makes it one of the most cost-effective solutions in the market without compromising on quality.
For a better understanding of where it stands in the market, the following comparison table with specifications is provided:
|
Feature |
Growatt SPF 3000TL HVM-24 |
Other 3kW Inverters |
|
Efficiency |
Up to 97% |
94-96% |
|
Operating Modes |
Hybrid, grid-tie, off-grid |
Varies; often limited |
|
Display |
Remote monitored LCD |
App-dependent or limited indicators |
|
Protection |
Extensive protection features |
Varied, often partial |
|
Battery Compatibility |
Broad compatibility |
Limited in some models |
|
Size & Weight |
Light in weight |
Larger or heavier |
The comparison thus highlights the Growatt SPF 3000TL HVM-24’s greater versatility and efficiency.
When reading through the growatt spf 3000tl hvm-24 datasheet and planning your system, keep these in mind:
With the fast-evolving solar technology, having a quality inverter is imperative. With the Growatt Inverter SPF 3000TL HVM-24 having a power reflection feature, efficiency, and versatility, it is one of the best investments for those moving towards energy autonomy and sustainability.
Having the ability to have diversified applications ranging from cabin off-grids to hybrid home installations, it is the best manifestation of Growatt’s reliability and creativity.
Growatt is a name that has established itself as one of the leaders in the solar energy industry with its value-for-money products that are attuned to the current adopters of solar power. Whether you are an installer, homeowner, or solar equipment user, SPF 3000TL HVM-24 is a tested and proven solution to illuminate your solar dream in comfort.
Begin your solar journey today with the Growatt SPF 3000TL HVM-24! Join the future of clean, efficient power!
Yes, since it is an inverter that is being offered in the hybrid model format, it can be made possible that the unit can be used in the off-grid, grid-connected, and hybrid modes such that there are configurations of nature available.
The inverter accepts a few battery models within a limited capacity; please refer to the growatt spf 3000tl hvm-24 datasheet for specifications and compatibility.
Yes. Remote monitoring via the Growatt Shine App has support from the inverter so that users can easily remotely monitor and troubleshoot.
Recommended regular maintenance, cleaning, and software updating if needed. Heavy duty build of inverter makes it zero effort to maintain.
growatt spf 3000tl hvm-24 manual can be downloaded from Growatt company website or via distributors. It has step-by-step installation and use manual.
