| On Grid 100 KW Three Phase
5 Years Warranty |
·10 MPPTs fusefree design
·Smart I/V scan and diagnosis
·Intelligent string monitoring
·AC&DC type II SPD
·IP66 protection
$ 3,133
| Datasheet | MAX 100KTL3-X LV | MAX 110KTL3-X LV | MAX 120KTL3-X LV | MAX 125KTL3-X LV |
| Input data (DC) | ||||
| Max. DC voltage | 1100V | |||
| Start voltage | 195V | |||
| Nominal voltage | 600V | |||
| MPP voltage range | 180V-1000V | |||
| No. of MPP trackers | 10 | |||
| No. of PV strings per MPP tracker | 2 | |||
| Max. input current per MPP tracker | 32A | |||
| Max. short-circuit current per MPP tracker | 40A | |||
| Output data (AC) | ||||
| AC nominal power | 100000W | 110000W | 120000W | 125000W |
| Max. AC apparent power | 110000VA | 121000VA | 132000VA | 137500VA |
| Nominal AC voltage (range*) | 220V/380V, 230V/400V (340-440V) | |||
| AC grid frequency (range*) | 50/60 Hz(45~55Hz/55-65 Hz) | |||
| Max. output current | 158.8A@400V
167.1A@380V |
174.6A@400V
183.8A@380V |
190.5A@400V
200.5A@380V |
198.5A@400V
208.9A@380V |
| Adjustable power factor | 0.8leading 0.8lagging | |||
| THDi | <3% | |||
| AC grid connection type | 3W/N/PE | |||
| Efficiency | ||||
| Max.efficiency | 98.8% | |||
| European efficiency | 98.4% | 98.5% | 98.5% | 98.5% |
| MPPT efficiency | 99.9% | |||
| Protection devices | ||||
| DC reverse polarity protection | Yes | |||
| DC switch | Yes | |||
| AC/DC surge protection | Type II / Type II | |||
| Insulation resistance monitoring | Yes | |||
| AC short-circuit protection | Yes | |||
| Ground fault monitoring | Yes | |||
| String detection | Yes | |||
| Anti PID function | Optional | |||
| Arc fault detection (AFCI) | Optional | |||
| General data | ||||
| Dimensions (W / H / D) | 970/640/345mm | |||
| Weight | 84kg | |||
| Operating temperature range | –30°C … +60°C | |||
| Nighttime power consumption | < 1W | |||
| Topology | Transformerless | |||
| Cooling | Smart air cooling | |||
| Protection degree | IP66 | |||
| Relative humidity | 0~100% | |||
| Altitude | 4000m | |||
| DC connection | H4/MC4 (Max.6mm²) | |||
| AC connection | OT Terminal (Max. 240mm²) | |||
| Display | LED/WIFI+APP | |||
| Interfaces: RS485 / USB
/PLC/GPRS/4G/WiFi |
Yes/Yes/Optional/Optional/Optional/Optional | |||
| Warranty: 5 years / 10 years | Yes /Optional | |||
| CE, UKCA, IEC62116, IEC61727, CQC, VDE0126, VFR2019, EN50549-1/-2, C10/C11, UNE206007, G99 CEI 0-21/0-16, N4105, UNE206006,MEA, PEA, KSC8565 | ||||
The Growatt Inverter MAX 100KTL3-X LV is a reliable and efficient choice for commercial and industrial solar energy projects. Delivering up to 100 kW of power, this inverter helps you maximize your solar energy output while cutting down on electricity expenses. If you’re looking to buy a high-performance inverter at a reasonable price, the MAX 100KTL3-X LV offers excellent value for your money.
Thanks to its high efficiency, the MAX 100KTL3-X LV converts more sunlight into usable electricity, ensuring you get the most out of your solar panels. Its sturdy design guarantees consistent performance even in challenging weather conditions, reducing maintenance needs and unexpected downtime. This makes it a smart investment for businesses that rely on stable energy supply.
The inverter also includes advanced monitoring capabilities, allowing you to track your system’s performance remotely and troubleshoot issues quickly. Its flexible installation options mean it can be tailored to fit a variety of solar setups with ease.
When considering the price, the Growatt MAX 100KTL3-X LV strikes a balance between affordability and cutting-edge technology. The long-term energy savings and durability help justify the purchase cost, making it a cost-effective solution for large-scale solar projects. Plus, Growatt provides solid warranty coverage and customer support worldwide.
In short, if you want to buy a dependable, efficient, and competitively priced inverter for your solar project, the Growatt MAX 100KTL3-X LV is a great pick. It delivers strong performance, smart features, and lasting reliability to help you save money and harness solar power effectively.
